Facom Midget Angled Open End Wrench - 3.2mm (1/8")(34.3,2) - The heads (angled at 15° and 75°) give access to fasteners that are inaccessible with standard wrenches. Short handle and very slim heads for manoeuvrability. Chrome finish. Available in metric sizes 3.2>17mm and fractional sizes 3/16">11/16" . 3.2mm is the same as 1/8".
The FACOM 34.3.2 (also cataloged as Proto FM-34.3.2) is a professional-grade 3.2 mm midget angled open-end wrench. This micromechanical specialty spanner is engineered for precise adjustments in highly confined, delicate assemblies like electronic modules, carburetor linkages, model engineering, and ignition systems.
Key Technical Specifications
- Fastener Size: 3.2 mm (equivalent to 1/8")
- Dual Head Offset Angles: One wrench end is set at a standard 15° angle, while the opposing end features an aggressive 75° angle. This allows technicians to flip the wrench to access fasteners completely blocked from top-down or straight-on approaches.
- Overall Length: 70 mm (~2.75 inches) for tight clearance handling.
- Ultra-Slim Head Profile: Head thickness is just 2.4 mm with an outer head width of 10 mm.
- Material & Finish: Forged from high-grade Chrome Vanadium alloy steel finished in premium satin chrome.
- Standard Compliance: NF ISO 3318, NF ISO 691, ISO 3318, ISO 691, and DIN ISO 691.
