Facom Separator for Bearing Extractions (25-250mm)(U.53T5) - Fits behind races where ordinary puller claws will not reach. They can be used with beams assisted by screws or jacks. Click on photos to enlarge for further details and specifications.
The FACOM U.53T5 is an industrial-grade heavy-duty bearing separator (odklejacz do łożysk) designed for the precise extraction of tightly grouped or seized bearings, gears, and inner races. Manufactured by FACOM, its wedge-shaped, tapered plates are engineered to slide behind components where traditional puller jaws cannot reach.
- Clamping/Spread Range: 25 mm to 250 mm.
- Tie Rod Thread Diameter (d1 / d2): M22 metric threads on the structural tension rods.
- Overall Structural Length (L): 430 mm.
- Tool Height (H): 316 mm.
- Net Component Weight: Highly robust at 11.20 kg.
- Global Barcode (EAN): 3148510703978.
System Compatibility & Function - The U.53T5 functions as a wedge base that clamps behind the target component. To finish pulling the part off a shaft, the separator must be paired with mechanical pulling beams or threaded rods. It is specifically built to integrate directly with:
- Mechanical Beam Pullers: Compatible with the heavy-duty FACOM U.53K4 and FACOM U.53S4A structural counter-support systems.
- Operation: Driven via mechanical screws or assisting hydraulic jacks.
